High Performance Digital Speed Indicator With Double Electric Control Air Valve

Double electric control air valve solenoid vavle DCF23S Double action pilot solenoid valve DC220V

DN : 10mm  15mm

Working pressure : 0.15 ~ 0.9MPA

Working voltage : DC220V DC110V DC24V AC220V

DCF23S double solenoid air valve is two position three way solenoid valve, through an electromagnet (off), open (closed) pilot hole end of the valve, the spool, controlled fluid reversing, for hydropower station and air brake band seal, but also can be used for thermal power, metallurgy, machinery, chemical industry, working in the medium for the compressed air in the pipeline, in order to realize the automatic remote control. This product features: small size, light weight, reliable operation, the electromagnetic coil for a short time, small driving power, it is not easy to damage. With manual control mechanism with self-locking function. It is through the electromagnet General Electric (off), open (closed) pilot hole end of the valve, the spool, controlled fluid reversing, for hydropower station and air brake band seal, but also can be used for thermal power, machinery, metallurgy, chemical industry, working in the medium for the compressed air in the pipeline, with the To achieve remote automatic control. This product features: small size, light weight, reliable work, electromagnetic coil for a short time to work, driving power is small, not easy to damage. With manual control mechanism, with self-locking function.

speed measuring instrument

digital panel indicator

High Performance Digital Speed Indicator With Double Electric Control Air Valve Images
